Product
Jinko Solar 650W
In stockPrice
₦146,630
Specification Data Brand
Jinko Solar Series Tiger Neon Model
JKM650N-66HL4M-BDV Rated Maximum Power (Pmax) 650WTechnologyN-Type TOPCon Panel Type Bifacial Dual-Glass Cell Type N-Type Monocrystalline Number of Cells 132 (66 × 2) Maximum Power Voltage (Vmp) 41.58V Maximum Power Current (Imp)n15.64A Open Circuit Voltage (Voc) 50.28V Short Circuit Current (Isc) 16.44A Module Efficiency Approx. 24.1% Power Tolerance 0 to +3%
Maximum System Voltage 1500V DC Maximum Series Fuse 35A Dimensions
2382 × 1134 × 30 mm Weight Approx. 32.4 kg Front Glass 2.0 mm anti reflection coated glass Back Glass 2.0 mm heat-strengthened glass Frame Anodized aluminium alloy Junction Box IP68 rated Operating Temperature -40°C to +70°C Front Static Load Up to 5400 Rear Static Load Up to 2400 PaProduct Warranty 12 years Linear Power Warranty 30 years
Jinko Solar Series Tiger Neon Model
JKM650N-66HL4M-BDV Rated Maximum Power (Pmax) 650WTechnologyN-Type TOPCon Panel Type Bifacial Dual-Glass Cell Type N-Type Monocrystalline Number of Cells 132 (66 × 2) Maximum Power Voltage (Vmp) 41.58V Maximum Power Current (Imp)n15.64A Open Circuit Voltage (Voc) 50.28V Short Circuit Current (Isc) 16.44A Module Efficiency Approx. 24.1% Power Tolerance 0 to +3%
Maximum System Voltage 1500V DC Maximum Series Fuse 35A Dimensions
2382 × 1134 × 30 mm Weight Approx. 32.4 kg Front Glass 2.0 mm anti reflection coated glass Back Glass 2.0 mm heat-strengthened glass Frame Anodized aluminium alloy Junction Box IP68 rated Operating Temperature -40°C to +70°C Front Static Load Up to 5400 Rear Static Load Up to 2400 PaProduct Warranty 12 years Linear Power Warranty 30 years
- Brand: Jinko
- Power rating: 650W
- Voltage: 41.58V
- Warranty: 12 years
- Specification Data Brand
Delivery
Estimated delivery in 3-7 working days with order tracking.
Installation support
Professional installation can be arranged within 7 working days.
Seller
Why buy here
- Verified marketplace seller
- Official warranty and after-sales support
- Fast delivery updates and responsive service
0.0
0 ratingsNo reviews yet. Be the first to share feedback.
Customer Feedback
0.0
0 ratingsNo reviews yet. Be the first to share feedback.
Solar PanelsIn stock
Jinko Solar 650W
0.0
0 customer ratingsPrice
₦146,630
Key Features
- Brand: Jinko
- Power rating: 650W
- Voltage: 41.58V
- Warranty: 12 years
- Specification Data Brand
Description
Specification Data Brand
Jinko Solar Series Tiger Neon Model
JKM650N-66HL4M-BDV Rated Maximum Power (Pmax) 650WTechnologyN-Type TOPCon Panel Type Bifacial Dual-Glass Cell Type N-Type Monocrystalline Number of Cells 132 (66 × 2) Maximum Power Voltage (Vmp) 41.58V Maximum Power Current (Imp)n15.64A Open Circuit Voltage (Voc) 50.28V Short Circuit Current (Isc) 16.44A Module Efficiency Approx. 24.1% Power Tolerance 0 to +3%
Maximum System Voltage 1500V DC Maximum Series Fuse 35A Dimensions
2382 × 1134 × 30 mm Weight Approx. 32.4 kg Front Glass 2.0 mm anti reflection coated glass Back Glass 2.0 mm heat-strengthened glass Frame Anodized aluminium alloy Junction Box IP68 rated Operating Temperature -40°C to +70°C Front Static Load Up to 5400 Rear Static Load Up to 2400 PaProduct Warranty 12 years Linear Power Warranty 30 years
Jinko Solar Series Tiger Neon Model
JKM650N-66HL4M-BDV Rated Maximum Power (Pmax) 650WTechnologyN-Type TOPCon Panel Type Bifacial Dual-Glass Cell Type N-Type Monocrystalline Number of Cells 132 (66 × 2) Maximum Power Voltage (Vmp) 41.58V Maximum Power Current (Imp)n15.64A Open Circuit Voltage (Voc) 50.28V Short Circuit Current (Isc) 16.44A Module Efficiency Approx. 24.1% Power Tolerance 0 to +3%
Maximum System Voltage 1500V DC Maximum Series Fuse 35A Dimensions
2382 × 1134 × 30 mm Weight Approx. 32.4 kg Front Glass 2.0 mm anti reflection coated glass Back Glass 2.0 mm heat-strengthened glass Frame Anodized aluminium alloy Junction Box IP68 rated Operating Temperature -40°C to +70°C Front Static Load Up to 5400 Rear Static Load Up to 2400 PaProduct Warranty 12 years Linear Power Warranty 30 years
